Premium line Cable Cat. 6 U/UTP
Standards:
- ANSI/TIA-568.2-D:2018
- ISO/IEC 11801-1:2017
- CENELEC EN 50173-1
- CENELEC EN 50288-6-1
- Flame retardancy is verified according to IEC 60332-1-2
- 3P certified
- ETL certified
- RoHS compliant
- Application:
- 1000BASE-TX (Gigabit Ethernet)
- 1000BASE-T (Gigabit Ethernet)
- 100BASE-TX Fast Ethernet
- 10BASE-T Ethernet
- Voice
Construction
Conductor Material / size Bare Copper / 23 AWG Insulation Material HDPE Sheath Material PVC / LSOH Diameter 6.2* 0.3 mm Mechanical & Environmental Characteristics
Bending Radius 6D, without load 8D, with load Operation Temperature -20C ~+60C Installation Temperature 0C ~+50C Storage Temperature -30C ~+60C - 206141115
